VAST Power Systems, Inc. (VAST) is developing an external combustor that uses water or some other inert thermal diluent rather than air to cool combustion. This technology has allowed the demonstration (through computer simulations and empirical lab testing) of a number of significant benefits.

A Confidentiality and Non-Disclosure Agreement is necessary before details can be given on the ‘how’ and ‘why’ specifics. The following are a few of the benefits expected from the VAST technology.

Lowered Emissions Fuel Flexibility: from Nat. Gas to crude
Improved Cycle Efficiency Wide Range of Operating Temperatures
Improved Economics (IRR) Distributed Generation of Heat & Power
More Power from Smaller Turbines
(Increased Power Density)
Distributed Generation of CO2
for Enhanced Oil Recovery (EOR)

Lowered Emissions

VAST achieves ultra-low emissions levels using natural gas (without requiring post combustion catalytic cleanup); low single digit ppm levels for nitrogen oxides (NOx) simultaneously with low single digit carbon monoxide (CO) and unburned hydrocarbons (UBHC). The VASThermogenerator™ avoids forming pollutants during combustion so they do not have to removed afterwards.

The CFD (Computational Fluid Dynamics) software simulations by Combustion Science and Engineering, Inc. of Columbia, Maryland using Star CD combustion modeling software show very encouraging results. EPA-certified stack gas testing labs have independently verified bench-scale VAST Progressive Combustion apparatus burning propane to have simultaneously reached sub- 1 ppm levels for both NOX and CO.

Improved Economics (IRR)

In power generation and especially in CHP applications, VAST efficiency levels achieved during off-peak operations combined with low CapEx and O&M costs offer the prospect of improved payback benefits.

Thermoeconomic analysis by a consulting team from the Power and Transportation Division of the Engineering Department of the University of Genoa, Genoa, Italy, shows CHP efficiencies for VAST that are better than STIG cycles and at CapEx costs 10% to 25% lower. VAST Cycles show the promise of Internal Rates of Return (IRR) for power generation that are markedly better than the five leading competitive cycles, especially at partial loads of 4,000 hours/year or less.

The ability of a VASThermogenerator to better insure precise and uniform temperatures translates into lower Operating And Maintenance (O&M) costs. This cost saving is enhanced by the simplicity of the VAST combustor design.

Multi-fuel capability also enhances economic performance.

Fuel Flexibility: from Natural Gas to Crude Oil

The VAST combustor can burn multiple fuels with little adjustment. We have burned Propane, #2 Diesel, various heavy fuel oils, and Bunker Crude.

Our ability to control the combustion process more effectively enables VAST to provide very precise control of both temperature and pressure to meet various process requirements. Also, this ability allows improved uniformity and thereby minimizes hot or cold spots with their accompanying problems such as NOx and CO emissions.

A small bench model (0.57 MW) was built and tested in the mid 1990’s with encouraging results. In these test runs, VAST demonstrated +/- 1 degree F precision at turbine combustion temperatures. This precise and more uniform temperature and pressure controllability translates into improved equipment reliability and reduced operating costs.

Multiple Applications

We believe that the VAST technology can be utilized in many applications including

  • Distributed Generation/Combined Cooling, Heat And Power (DG/CCHP)
  • Enhanced Oil Recovery (EOR)
  • Bitumen heating in oil sands via SAGD or CSS
  • Brownfield remediation where large amounts of petroleum have been spilled
  • Open ocean oil spill response equipment, especially for spills of crude oil
  • Liquid and gaseous waste elimination such as oil well flare gas or sewage or waste dump biogas
  • Oily water waste streams from interior pressure washing of petroleum transport vessels’ heavy oil storage tanks or aircraft carrier flight deck washdown

In all of these combustion applications, VASTech can maintain homogeneous temperature profiles or provide spatial and temporal temperature distributions to achieve optimal heating characteristics for process applications. We can easily change temperature profiles dynamically in real-time. We can handle widely variable Btu rates as a result of variable off-gas composition or sudden increases in heat demand or combustion intensity.

VASThermogenerators have demonstrated stable combustion with ultra-low pollution profiles with primary combustion temperature ranges as low as 700 degrees C. VASThermogenerators also can handle combustion temperatures over the full range of fuel combustion, though as temperatures exceed around 2,300 degrees F, NOx formation occurs in our cycle, as in any other cycle in which hot spots exceed such temperatures. The difference in the VASThermogenerator is that we can select the temperature desired and minimize hot spots, virtually eliminating them.

The result is that VASTgas™, what we call the energetic working fluid created by a VASThermogenerator, has very, very low levels of pollutants in it, even without any post-combustion hot gas clean up by catalytic converter or other treatment protocol. Because of the VAST Wet Cycle and the VAST Progressive Combustion™ processes used in VASThermogenerators, VASTgas does not need post-combustion treatment to meet and exceed current air quality control standards such as those set by the South Coast Air Quality Management District (AQMD) of Southern California – the region with the strongest emission control regulations in the USA.

Intellectual Property

VAST has 34 active patents (17 issued in the USA + 17 issued overseas), with many more in various stages of the patent-pending process in different countries. Over $6 million has been invested in filing over 65 independent claims with over 1,100 dependent claims in our patent portfolio.

Market Focus

A marketing study done for VAST by Sargent & Lundy recommended that we focus initially on the Distributed Generation market because our efficiencies are less affected by scale than are most power cycles. Our pollution control technology is also much less sensitive to scale than most power cycle pollution control technologies. This should enable the VAST Wet Combustion Power Cycle to achieve higher efficiencies and less costly pollution control than other systems operating in these lower MW size ranges. Additionally, our potentially small footprint per kW would add a competitive advantage in these smaller size ranges.

Studies performed by consultants at the University of Genoa, in Italy, quantified substantial thermoeconomic advantages in the small to medium size range systems; e.g., 5 MW to 50 MW. Therefore, we welcome any opportunities to explore potential cooperation with counterparts in various sectors of the power generation market. We are now in the process of refining our computer models under a Department of Energy (DOE) research grant from the High-Performance Computing for Manufacturing (HPC4Mfg) Project team at the DOE’s Lawrence Livermore National Laboratory.

This $300,000 grant funds a one year project involving both Lawrence Livermore and Argonne National Laboratory. The grant supports the development of a CAD and CFD model of the VAST® Scalable Combustor. CFD runs on the Argonne supercomputer will seek to identify more effective trade-offs between the many design variables in the Vast combustor. LLNL will then analyze the terabyte of data gained in the 729 optimization runs. They have developed machine learning protocols that facilitate the analysis of big data collections such as the VAST combustor CFD runs will generate. Their resulting surrogate equations will allow the VASTeam™ to do further modeling without the necessity of a supercomputer.

A contract has been negotiated with the University of Notre Dame for performing empirical lab verification of the ANL & LLNL model’s results. These will be significant additional steps forward in our journey toward commercialization. If you are interested in exploring the possibility of participating in this effort, we would be happy to present our technology in more detail.

Developmental Research

VAST is an energy technology company in its R&D phase and has not yet embodied its technical solutions in specific operating equipment or processes. We do sufficiently understand the underlying combustion science and thermodynamics and have solved most of the initial engineering problems inherent in applying the VAST Wet Combustion Cycle to a Distributed Generation application. VAST Power Systems, Inc. is now beginning to seek counterparts with whom we can partner to finish the technical R&D, perform appropriate empirical verifications and CFD model parameterization. Ultimately, such a counterpart would undertake the commercialization of the VASTechnology™ in those sectors of technical practice in which they see the potential for VASTech™ to further their commercial objectives.
